Low Voltage Cables - 300/500V & 450/750V Description : Soft annealed solid or stranded Copper conductors insulated with PVC compound rated 70 °C or 90 °C according to IEC 60227 & BS 6004. Application : For indoor fixed installations in dry locations, laid in conduits, as well as in steel support brackets. |
|
|
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Multicore cables of Stranded Aluminum conductors are insulated with XLPE compound, assembled together and covered with an overall jacket of PVC compound.Cables are produced according to IEC 60502 . Application : For outdoor and indoor installations in damp and wet locations.They are normally used for power distribution in urban networks, in industrial plants as well as in Thermopower and Hydropower Stations. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Multicore cables of stranded Aluminum conductors are insulated with PVC compound rated 70ºC, assembled together, armored with steel wires and covered with overall jacket of PVC compound.Cables are produced according to IEC 60502 or BS 6346. Application : For outdoor installations in damp wet locations where mechanical damages are expected to occur. |
|
|
Low Voltage Cables - 300/500V & 450/750V Description : Soft annealed Copper fine wires, bunched together in subunits or stranded bunched groups into a main units, which forms the flexible conductor. Insulated with soft PVC 70 °C or 90 °C Compound.Cables are produced according to IEC 60227 or BS 6004. Application : For indoor fixed installations in dry locations, where particular flexibility is required. For electrical panels connection or for electrical apparatus they can be laid in groups around steel sheets. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Multicore cables of stranded Copper conductors are insulated with PVC compound rated 70°C, assembled together, armored with steel tape and covered with overall jacket of PVC compound.Cables are produced according to IEC 60502. Application : For outdoor installations in damp and wet locations, where mechanical damages are expected to occur. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Soft annealed stranded Copper or Aluminum conductor.Insulated with PVC compound rated 70 °C and sheathed with PVC Compound layer .Cables are produced according to IEC 60502. Application : For outdoor and indoor installations in damp and wet locations. They are normally used for power distribution in urban networks, industrial plants, as well as in thermopower and hydropower stations. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Soft annealed stranded Copper or Aluminum conductor, Insulated with XLPE compound covered with a layer of PVC compound to form the overall jacket.Cables are according to IEC 60502 or BS 7889. Application : For outdoor and indoor installations in damp and wet locations.They are normally used for power distribution in urban networks, in industrial plants, as well as in Thermopower and Hydropower stations. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Multicore cables of stranded Aluminum conductors are insulated with XLPE compound, assembled together, armored with steel tape and covered with an overall jacket of PVC compound.Cables are produced according to IEC 60502. Application : For outdoor installations in damp wet locations where mechanical damages are expected to occur. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Multicore cables of stranded Copper conductors are insulated with PVC compound rated 70°C, assembled together, covered with overall jacket of PVC compound.Cables are produced according to IEC 60502. Application : For outdoor and indoor installations in damp and wet locations. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Multicore cables of stranded Copper conductors are insulated with PVC compound rated 70°C, assembled together, armored with steel wires and covered with overall jacket of PVC compound.Cables are produced according to IEC 60502 or BS 6346. Application : For outdoor installations in damp wet locations where mechanical damages are expected to occur. |
|
|
Low Voltage Cables - 300/500V Description : Soft annealed stranded Copper or Aluminum conductor, Insulated with XLPE compound covered with a layer of PVC compound to form the overall jacket.Cables are according to IEC 60502 or BS 7889. Application : For outdoor and indoor installations in damp and wet locations.They are normally used for power distribution in urban networks, in industrial plants, as well as in Thermopower and Hydropower stations. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Multicore cables of stranded Aluminum conductors are insulated with PVC compound rated 70°C, assembled together, covered with overall jacket of PVC compound.Cables are produced according to IEC 60502. Application : For outdoor and indoor installations in damp and wet locations. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Multicore cables of stranded Copper conductors are insulated with XLPE compound, assembled together, armored with steel tape and covered with an overall jacket of PVC compound.Cables are produced according to IEC 60502. Application : For outdoor installations in damp wet locations where mechanical damages are expected to occur. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Multicore cables of Stranded Aluminum conductors are insulated with XLPE compound, assembled together and covered with an overall jacket of PVC compound.Cables are produced according to IEC 60502. Application : For outdoor and indoor installations in damp and wet locations.They are normally used for power distribution in urban networks, in industrial plants as well as in Thermopower and Hydropower Stations. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Soft annealed stranded Copper or Aluminium conductor.Insulated with PVC compound rated 70 °C and sheathed with PVC Compound layer .Cables are produced according to IEC 60502. Application : For outdoor and indoor installations in damp and wet locations. They are normally used for power distribution in urban networks, industrial plants, as well as in thermopower and hydropower stations. |
|
|
Low Voltage Cables - 0.6/1 (1.2) KV Description : Multicore cables of stranded Copper conductors are insulated with XLPE compound, assembled together, armored with steel wires and covered with an overall jacket of PVC compound.Cables are produced according to IEC 60502 or BS 5467 Application : For outdoor installations in damp wet locations where mechanical damages are expected to occur. |
